| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | CONTROL VALVE ASSEMBLY - FLOAT (SEE FIG. H0970-6230) | SN: A40001-- |
H0970-6230 | ||||
| ? | 723-11-25211 | • SPOOL | 1 | SN: A40001-- |
|||
| ? | 723-11-25221 | • PISTON | 1 | SN: A40001-- |
|||
| ? | 723-11-28530 | • RETAINER | 1 | SN: A40001-- |
|||
| ? | 723-11-28540 | • SPRING | 1 | SN: A40001-- |
|||
| ? | 723-11-25151 | • VALVE | 1 | SN: A40001-- |
|||
| ? | 723-11-28551 | • SPRING | 1 | SN: A40001-- |
|||
| ? | 723-11-27720 | • SEAT, NOZZLE SPRING | 1 | SN: A40001-- |
|||
| ? | 723-11-29380 | • PLATE | 1 | SN: A40001-- |
|||
| ? | 722-12-19120 | • O-RING | 1 | SN: A40001-- |
|||
| ? | 723-11-29390 | • O-RING | 2 | SN: A40001-- |
|||
| ? | 723-11-18150 | • O-RING | 1 | SN: A40001-- |
|||
| ? | 07000-11007 | • O-RING | 2 | SN: A40001-- |
|||
| ? | 723-11-17450 | • PLUG | 1 | SN: A40001-- |
|||
| ? | 07002-10823 | • O-RING | 1 | SN: A40001-- |
|||
| ? | 01252-60620 | • SCREW | 5 | SN: A40001-- |
|||
| ? | 01252-60625 | • SCREW | 7 | SN: A40001-- |
|||
| ? | 723-11-29440 | • GASKET | 1 | SN: A40001-- |
|||
| ? | • BODY (SEE FIG. H1040-6244) | SN: A40001-- |
H1040-6244 |
