| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | CONTROL VALVE ASSEMBLY - STANDARD (SEE FIG. H0860-6200) | SN: A40001-- |
H0860-6200 | ||||
| ? | 723-11-01153 | • CASE ASSEMBLY | 1 | SN: A40001-- |
|||
| ? | 723-11-27643 | • • BODY | 1 | SN: A40001-- |
|||
| ? | 723-11-19640 | • • PLUG | 1 | SN: A40001-- |
|||
| ? | 723-11-18820 | • • PLUG | 1 | SN: A40001-- |
|||
| ? | 07002-11023 | • • O-RING | 1 | SN: A40001-- |
|||
| ? | 723-11-27480 | • • SEAT | 1 | SN: A40001-- |
|||
| ? | 700-84-11730 | • • BALL | 1 | SN: A40001-- |
|||
| ? | 723-11-17970 | • • ORIFICE | 1 | SN: A40001-- |
|||
| ? | 722-12-19120 | • • O-RING | 1 | SN: A40001-- |
|||
| ? | 723-16-54490 | • • PLUG | 3 | SN: A40001-- |
|||
| ? | 702-21-54260 | • • O-RING | 3 | SN: A40001-- |
|||
| ? | 723-11-29710 | • • ORIFICE | 1 | SN: A40001-- |
|||
| ? | 723-11-01390 | • CASE ASSEMBLY | 1 | SN: A40001-- |
|||
| ? | 723-11-27661 | • • BODY | 1 | SN: A40001-- |
|||
| ? | 723-11-27480 | • • SEAT | 1 | SN: A40001-- |
|||
| ? | 723-84-11730 | • • BALL | 1 | SN: A40001-- |
|||
| ? | 723-11-17970 | • • ORIFICE | 1 | SN: A40001-- |
|||
| ? | 722-12-19120 | • • O-RING | 1 | SN: A40001-- |
|||
| ? | 723-11-27490 | • • PLATE | 1 | SN: A40001-- |
|||
| ? | 723-11-18150 | • • O-RING | 1 | SN: A40001-- |
|||
| ? | 723-11-27980 | • • PISTON | 1 | SN: A40001-- |
|||
| ? | 702-16-54490 | • • DOWEL | 3 | SN: A40001-- |
|||
| ? | 702-21-54260 | • • O-RING | 2 | SN: A40001-- |
|||
| ? | 702-16-53920 | • • O-RING | 1 | SN: A40001-- |
|||
| ? | • SCREW (SEE FIG. H0930-6214) | SN: A40001-- |
H0930-6214 |
