| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HYDRAULIC PUMP ASSEMBLY - HIGH-FLOW (SEE FIG. H0750-6126) | SN: A40001-- |
H0750-6126 | ||||
| ? | • HYDRAULIC PUMP (SEE FIG. H0750-6126) | SN: A40001-- |
H0750-6126 | ||||
| ? | 720-2T-03140 | • • COVER ASSEMBLY | 1 | SN: A40001-- |
F1 | ||
| ? | 720-2T-14521 | • • • COVER | 1 | SN: A40001-- |
F1 | ||
| ? | 720-2T-14532 | • • • SPOOL | 1 | SN: A40001-- |
F1 | ||
| ? | 720-21-55620 | • • • PLUG | 2 | SN: A40001-- |
|||
| ? | 07002-61423 | • • • O-RING | 2 | SN: A40001-- |
|||
| ? | 720-2T-14430 | • • • SCREW, ADJUSTING | 1 | SN: A40001-- |
F1 | ||
| ? | 07000-11008 | • • • O-RING | 1 | SN: A40001-- |
F1 | ||
| ? | 01582-11008 | • • • NUT | 1 | SN: A40001-- |
F1 | ||
| ? | 07000-12065 | • • O-RING | 2 | SN: A40001-- |
F1 | ||
| ? | 01252-61025 | • • SCREW | 8 | SN: A40001-- |
|||
| ? | 07000-B2014 | • • O-RING | 2 | SN: A40001-- |
F1 | ||
| ? | • • BLOCK, VALVE (SEE FIG. H0750-6126) | SN: A40001-- |
H0750-6126 | ||||
| ? | • • COVER ASSEMBLY (SEE FIG. H0800-6136) | SN: A40001-- |
H0800-6136 | ||||
| ? | 15 | ||||||
| ? | F1 - THIS PART IS SUPPLIED AS AN ASSEMBLY. HOWEVER, IT IS SUPPLIED AS AN INDIVIDUAL PART BY AUTHORIZED DISTRIBUTORS ONLY. | 16 |
