| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HYDRAULIC PUMP ASSEMBLY (SEE FIG. H0620-6100) | SN: A40001-- |
H0620-6100 | ||||
| ? | 720-2T-03510 | • VALVE ASSEMBLY | 1 | SN: A40001-- |
|||
| ? | 720-2T-03520 | • • BLOCK, VALVE | 1 | SN: A40001-- |
F1 | ||
| ? | (NSS) | • • • BLOCK | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • • PLUG | 1 | SN: A40001-- |
|||
| ? | 706-8E-14110 | • • • PLUG | 2 | SN: A40001-- |
F1 | ||
| ? | 07002-11023 | • • • O-RING | 2 | SN: A40001-- |
F1 | ||
| ? | (NSS) | • • • SPOOL | 2 | SN: A40001-- |
|||
| ? | 720-2T-15640 | • • • SPRING | 2 | SN: A40001-- |
F1 | ||
| ? | (NSS) | • • • SLEEVE | 2 | SN: A40001-- |
|||
| ? | 07002-11823 | • • • O-RING | 2 | SN: A40001-- |
F1 | ||
| ? | 702-77-11470 | • • • SEAL | 2 | SN: A40001-- |
F1 | ||
| ? | 708-8E-16150 | • • PLUG | 2 | SN: A40001-- |
|||
| ? | 07002-11023 | • • O-RING | 2 | SN: A40001-- |
|||
| ? | 01252-60645 | • • BOLT | 4 | SN: A40001-- |
|||
| ? | 07000-11009 | • • O-RING | 2 | SN: A40001-- |
|||
| ? | • CASE ASSEMBLY, PUMP (SEE FIG. H0620-6100) | SN: A40001-- |
H0620-6100 | ||||
| ? | 17 | ||||||
| ? | F1 - THIS PART IS SUPPLIED AS AN ASSEMBLY. HOWEVER, IT IS SUPPLIED AS AN INDIVIDUAL PART BY AUTHORIZED DISTRIBUTORS ONLY. | 18 |
