Содержание Bulldozers Komatsu D32E-1/P-1 S/N P075501-P075717(D32EP1)
FUEL PUMP(12-076 : E4AO410N.001)
Номер на схеме Каталожный номер Название Количество Детали
? 1240 835 H1 PUMP, FUEL 1 R1
? 1240 689 H1 • KIT, SOLENOID 12V 1
? 1262 993 H1 • KIT, THROTTLE LEVER 1
? 1240 265 H1 • LEVER, SHUT OFF 1
? 1240 266 H1 • SPRING, SHUT OFF 1
? 1240 267 H1 • NUT, LOCK 3
? 1240 268 H1 • O-RING 1
? 1240 269 H1 • WASHER 3
? 1240 270 H1 • SCREW, IDLE SET 2
? 1240 271 H1 • WASHER, FLAT 2
? 1240 272 H1 • NUT, SELF LOCKING 1
? 1240 273 H1 • ORIFICE, BLEED 1
? 1240 274 H1 • FITTING, INLET 1
? 1240 275 H1 • WASHER, COPPER INLET 1
? 1240 276 H1 • FITTING, RETURN 1
? 1240 277 H1 • WASHER, SEALING 9
? 1240 278 H1 • FITTING, BANJO 4
? 1240 279 H1 • BOLT, BANJO 4
? 1240 280 H1 • COVER, INSPECTION 1
? 1240 281 H1 • GASKET, COVER 1
? 1240 282 H1 • BOLT, COVER 2
? 1240 283 H1 • ASSEMBLY, SCREW 2
? 1240 284 H1 • ASSEMBLY, SCREW 1
? 1240 285 H1 • FILTER, INLET 1
? 1240 286 H1 • WASHER, VENT SCREW 1
? 1240 287 H1 • WASHER, COPPER 1
? 1240 288 H1 • CAP, SEALING 1
? 1240 097 H1 • NUT, REGULAR HEXAGON JAM 1
? 1238 107 H1 • WASHER LOCK 1
? 1240 291 H1 • SPRING, SOLENOID 1
? 1240 292 H1 • SCREW, CAP (LOCKED TIMING) 1
? 1240 293 H1 • WASHER (LOCKED TIMING) 1
? 1240 294 H1 • SEAL (LOCKED TIMING) 1
? 1240 295 H1 • GUIDE, SPRING 1
? 1240 193 H1 • KEY, PLAIN WOODRUFF 1
? 1240 750 H1 • BRACKET 1
? 1240 801 H1 • WASHER, FIBER 2
? 1240 802 H1 • GASKET 1
? 1240 803 H1 • O-RING 4
? 1240 804 H1 • WASHER 1
? 1240 805 H1 • O-RING 2
? 1240 806 H1 • GASKET 1
? 1240 807 H1 • O-RING 2
? 1240 808 H1 • WASHER 1
? 1240 809 H1 • SPRING 1
? 1240 810 H1 • SPRING 1
? 1240 812 H1 • SPRING 1
? 1240 811 H1 • SPRING 1
? 1240 813 H1 • CHECKBALL 1
?
? R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED
? ASSEMBLIES CATALOG.
