| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 706-75-01150 | SWING MOTOR ASSEMBLY | 1 | SN: A85001 -- |
|||
| ? | 565-14-22440 | O-RING | 1 | SN: A85001 -- |
|||
| ? | 01252-61445 | BOLT | 8 | SN: A85001 -- |
|||
| ? | 706-75-43660 | SHAFT, DRIVE | 1 | SN: A85001 -- |
|||
| ? | 706-75-42880 | BEARING | 1 | SN: A85001 -- |
|||
| ? | 706-75-43810 | SPACER | 1 | SN: A85001 -- |
|||
| ? | 706-7E-11260 | • SPRING | 2 | SN: A85001 -- |
|||
| ? | 706-7E-11270 | • SEAT | 1 | SN: A85001 -- |
|||
| ? | 706-76-40890 | • BEARING | 1 | SN: A85001 -- |
|||
| ? | 706-75-05040 | • SPACER KIT | 1 | SN: A85001 -- |
|||
| ? | (NSS) | • SPACER, 3.1 MM | 1 | SN: A85001 -- |
|||
| ? | (NSS) | • SPACER, 3.4 MM | 1 | SN: A85001 -- |
|||
| ? | (NSS) | • SPACER, 3.7 MM | 1 | SN: A85001 -- |
|||
| ? | 04064-04518 | • RING, SNAP | 1 | SN: A85001 -- |
|||
| ? | 706-7E-11280 | • SEAL, OIL | 1 | SN: A85001 -- |
|||
| ? | 706-75-43720 | • SPACER | 1 | SN: A85001 -- |
|||
| ? | 07064-06220 | • RING | 1 | SN: A85001 -- |
|||
| ? | 706-75-43190 | • BLOCK, CYLINDER | 1 | SN: A85001 -- |
|||
| ? | 706-75-43741 | • PLATE, VALVE | 1 | SN: A85001 -- |
|||
| ? | 706-75-43750 | • PIN, DOWEL | 1 | SN: A85001 -- |
|||
| ? | 706-75-43120 | • SHAFT, CENTER | 1 | SN: A85001 -- |
|||
| ? | 706-75-43130 | • RING, CENTER | 1 | SN: A85001 -- |
|||
| ? | 706-75-41110 | • SPRING | 1 | SN: A85001 -- |
|||
| ? | 706-75-05020 | • RETAINER KIT | 1 | SN: A85001 -- |
|||
| ? | (NSS) | • • RETAINER | 1 | SN: A85001 -- |
|||
| ? | (NSS) | • • SCREW | 7 | SN: A85001 -- |
|||
| ? | 706-75-43160 | • PISTON SUB ASSEMBLY | 7 | SN: A85001 -- |
|||
| ? | 706-75-92130 | • PLATE | 1 | SN: A85001 -- |
|||
| ? | 706-75-92340 | • PLATE | 4 | SN: A85001 -- |
|||
| ? | 706-75-92350 | • DISK | 3 | SN: A85001 -- |
|||
| ? | 706-75-92380 | • PISTON, BRAKE | 1 | SN: A85001 -- |
|||
| ? | 706-75-92390 | • RING, BRAKE | 1 | SN: A85001 -- |
|||
| ? | 07000-12145 | • O-RING | 1 | SN: A85001 -- |
|||
| ? | 706-75-92310 | • O-RING | 2 | SN: A85001 -- |
|||
| ? | 706-75-92170 | • SPRING | 6 | SN: A85001 -- |
