| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 702-21-04220 | VALVE ASSEMBLY, LOCK | 1 | ||||
| ? | (NSS) | • BODY | 1 | ||||
| ? | (NSS) | • SPOOL | 1 | ||||
| ? | 702-21-31350 | • SEAT | 1 | ||||
| ? | 702-21-31231 | • SPRING | 1 | ||||
| ? | 702-21-31360 | • SPACER | 1 | ||||
| ? | 702-21-31241 | • PLUG | 1 | ||||
| ? | 07002-01823 | • O-RING | 1 | ||||
| ? | 07000-13030 | • O-RING | 1 | ||||
| ? | 07000-02020 | • O-RING | 1 | ||||
| ? | (NSS) | • BODY | 1 | ||||
| ? | 702-21-35141 | • VALVE, CHECK | 1 | ||||
| ? | 702-21-35130 | • SEAL | 1 | ||||
| ? | 702-21-35120 | • SPRING | 1 | ||||
| ? | 706-73-40330 | • BOLT | 4 | ||||
| ? | 01602-21030 | • WASHER | 4 | ||||
| ? | 709-70-74302 | • VALVE ASSEMBLY, SUCTION AND SAFETY | 1 | ||||
| ? | 709-70-71112 | • • SLEEVE | 1 | ||||
| ? | (NSS) | • • SLEEVE | 1 | ||||
| ? | (NSS) | • • POPPET | 1 | ||||
| ? | (NSS) | • • SEAL | 1 | ||||
| ? | (NSS) | • • PISTON | 1 | ||||
| ? | 709-70-71210 | • • SPRING | 1 | ||||
| ? | (NSS) | • • PLUG | 1 | ||||
| ? | (NSS) | • • SEAL | 1 | ||||
| ? | 709-70-71220 | • • SPRING | 1 | ||||
| ? | 07002-02434 | • • O-RING | 1 | ||||
| ? | (NSS) | • • POPPET | 1 | ||||
| ? | (NSS) | • • SPRING | 1 | ||||
| ? | (NSS) | • • SCREW | 1 | ||||
| ? | (NSS) | • • O-RING | 1 | ||||
| ? | (NSS) | • • NUT | 1 | ||||
| ? | 709-25-11390 | • • O-RING | 1 |
