| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 417-06-23211 | HEAD LAMP ASSEMBLY | 2 | SN: A80001-UP- |
|||
| ? | 417-06-23220 | • BULB, 62/62 W | 1 | SN: A80001-UP- |
|||
| ? | 417-06-23260 | • LENS | 1 | SN: A80001-UP- |
|||
| ? | 08056-00371 | • CONNECTOR | 1 | SN: A80001-UP- |
|||
| ? | 41G-06-13201 | LAMP ASSEMBLY | 2 | SN: A80001-UP- |
|||
| ? | 41G-06-13210 | • LENS, FRONT | 1 | SN: A80001-UP- |
|||
| ? | 41G-06-13220 | • LENS, REAR | 1 | SN: A80001-UP- |
|||
| ? | 41G-06-13230 | • BULB, 5 W | 1 | SN: A80001-UP- |
|||
| ? | 08105-12420 | • BULB, 25 W | 1 | SN: A80001-UP- |
|||
| ? | 01220-40425 | • SCREW | 4 | SN: A80001-UP- |
|||
| ? | 08037-02512 | GROMMET | 2 | SN: A80001-UP- |
|||
| ? | 417-06-A1510 | SUPPORT, LEFT | 1 | SN: A80001-UP- |
|||
| ? | 01584-01210 | NUT | 2 | SN: A80001-UP- |
|||
| ? | 01435-01230 | BOLT | 3 | SN: A80001-UP- |
|||
| ? | 417-06-23190 | PLATE | 1 | SN: A80001-UP- |
|||
| ? | 01023-10612 | SCREW | 4 | SN: A80001-UP- |
|||
| ? | 09415-03614 | CAP | 1 | SN: A80001-UP- |
|||
| ? | 417-06-A1520 | SUPPORT, RIGHT | 1 | SN: A80001-UP- |
|||
| ? | 01584-01210 | NUT | 2 | SN: A80001-UP- |
|||
| ? | 01435-01230 | BOLT | 3 | SN: A80001-UP- |
|||
| ? | 417-06-23190 | PLATE | 1 | SN: A80001-UP- |
|||
| ? | 01023-10612 | SCREW | 4 | SN: A80001-UP- |
|||
| ? | 09415-03614 | CAP | 1 | SN: A80001-UP- |
