| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6736-41-5110 | SUPPORT, ROCKER LEVER | 6 | ||||
| ? | (NSS) | • SUPPORT, ROCKER LEVER | 1 | ||||
| ? | (NSS) | • SHAFT, ROCKER LEVER | 1 | ||||
| ? | 6732-41-5200 | LEVER, ROCKER INTAKE | 6 | ||||
| ? | (NSS) | • LEVER, ROCKER | 1 | ||||
| ? | 6735-41-5560 | • SCREW, SET - 3/8-24 X 1 1/2 IN. | 1 | ||||
| ? | 6735-41-5550 | • NUT, HEAVY HEXAGON - 3/8-24 UNF | 1 | ||||
| ? | (NSS) | • INSERT, ROCKER LEVER | 1 | ||||
| ? | 6732-41-5400 | LEVER, ROCKER EXHAUST | 6 | ||||
| ? | (NSS) | • LEVER, ROCKER | 1 | ||||
| ? | OR | ||||||
| ? | 6735-41-5560 | • SCREW, SET - 3/8-24 X 1 1/2 IN. | 1 | ||||
| ? | 6735-41-5550 | • NUT, HEAVY HEXAGON - 3/8-24 UNF | 1 | ||||
| ? | (NSS) | • INSERT, ROCKER LEVER | 1 | ||||
| ? | 6732-41-5160 | WASHER, PLAIN - M19 | 12 | ||||
| ? | 6732-41-5170 | RING, RETAINING | 12 | ||||
| ? | 6732-41-5180 | BOLT - M8-1.25 X 75 | 6 | ||||
| ? | 6732-11-1640 | BOLT - M12-1.75 X 180 | 6 | ||||
| ? | 6732-41-3111 | ROD, PUSH | 12 |
