| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1299 224 H91 | SECTION ASSY, BLADE TILT | 1 | ||||
| ? | • POSITIONER, SPOOL (SEE PG 10-048) | -29 | 10BHTD9H.010 | ||||
| ? | • VALVE, LOAD CHECK (SEE PG 10-050) | -29 | 10BHTD9H.006 | ||||
| ? | (1299 238 H91) | • SEAL ASSY, SPOOL | -54 | F1 | |||
| ? | 850 880 C1 | • • RETAINER, SEAL | 1 | ||||
| ? | 1299 239 H1 | • • KIT, SEAL | 1 | ||||
| ? | (NSS) | • • • RING, BACK UP | 1 | ||||
| ? | (NSS) | • • • RING, SEAL | 1 | ||||
| ? | 1299 240 H1 | • KIT, SEAL PLATE | 1 | ||||
| ? | (NSS) | • • PLATE, SEAL | 1 | F2 | |||
| ? | (NSS) | • • BOLT, HEX - 1/4NCx1/2 | 2 | ||||
| ? | (NSS) | • SPOOL, SECTION | 1 | ||||
| ? | (NSS) | • HOUSING, SECTION | 1 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - FOR SHIPPING PURPOSES ONLY. USE FOR SERVICING SECTION. | ||||||
| ? |
