| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1277 082 H91 | VALVE ASSY, FOUR SPOOL CONTROL | 1 | ||||
| ? | 1299 222 H91 | • COVER ASSY, INLET | 1 | ||||
| ? | (NSS) | • • COVER, INLET | 1 | ||||
| ? | • • VALVE, SYSTEM RELIEF (SEE PG 10-038) | -29 | 10BHTD9H.008 | ||||
| ? | 9410 361 | • • PLUG, PORT | 1 | ||||
| ? | 368 269 R1 | • • RING, SEAL | 1 | ||||
| ? | • SECTION, BLADE LIFT (SEE PG 10-040) | -29 | 10BHTD9H.003 | ||||
| ? | • SECTION, BLADE TILT (SEE PG 10-042) | -29 | 10BHTD9H.004 | ||||
| ? | • SECTION, BLADE ANGLE (SEE PG 10-042) | -29 | 10BHTD9H.004 | ||||
| ? | • SECTION, RIPPER (SEE PG 10-042) | -29 | 10BHTD9H.004 | ||||
| ? | 1299 226 H91 | • COVER ASSY, OUTLET | 1 | ||||
| ? | (NSS) | • • COVER, OUTLET | 1 | ||||
| ? | 9410 362 | • • PLUG, PORT | 1 | ||||
| ? | 297 459 R1 | • • RING, SEAL | 1 | ||||
| ? | 1299 227 H1 | • KIT, BETWEEN SECTION | 5 | F1 | |||
| ? | (NSS) | • • RING, SEAL | 2 | ||||
| ? | (NSS) | • • RING, SEAL | 2 | ||||
| ? | 1299 229 H1 | • KIT, STUD | 1 | ||||
| ? | (NSS) | • • BOLT, MOUNTING | 3 | ||||
| ? | (NSS) | • • NUT, HEX | 3 | ||||
| ? | |||||||
| ? | F1 - SEAL KIT CONTAINS 2 SETS OF SEAL RINGS NOT USED ON THIS VALVE. | ||||||
| ? |
