Номер на схеме	Каталожный номер	Название	Количество
?		VALVE, THREE SPOOL CONTROL (SEE PG 10-034)	-29	10BHTD9H.009
?		VALVE, FOUR SPOOL CONTROL (SEE PG 10-036)	-29	10BHTD9H.001
?	9410 204	CONNECTOR	2
?	364 885 R1	RING, SEAL	2
?	1285 292 H1	VENT, ORIFICE - 0.281IN - TOP PORT ROD END	1
?	1271 300 H1	TUBE, ROD END	1
?	1271 301 H1	TUBE, HEAD END	1
?	1271 302 H1	TUBE, ROD END CROSSOVER	1
?	1271 303 H1	TUBE, HEAD END CROSSOVER	1
?	653 171 C1	CLAMP, TUBE	1
?	140 483 H	BOLT, HEX - 3/8NCx1-1/4	1
?	25 544 R1	WASHER, FLAT - 3/8	1
?	1271 310 H1	BRACKET, SUPPORT	1
?	1271 348 H1	HOSE, HEAD END	2
?	1271 350 H1	HOSE, ROD END	2
?	653 171 C1	CLAMP, HOSE	2
?	24 843 R1	BOLT, HEX - 3/8NCx2	2
?	25 553 R1	WASHER, FLAT - 3/8	2
?	25 544 R1	WASHER, FLAT - 3/8	2
?	26 241 H	SPACER, CLAMP	2
?		CYLINDER, LIFT (SEE PG 10-054)	-29	10BRTD8H.001
?	1277 346 H91	BRACKET, TUBE	2
?	689 475 C1	CLAMP, HOSE	2
?	653 171 C1	CLAMP, HOSE	2
?	24 842 R1	BOLT, HEX - 3/8NCx1-3/4	2
?	25 553 R1	WASHER, FLAT - 3/8	2
?	25 544 R1	WASHER, FLAT - 3/8	2
?	26 241 H	SPACER, CLAMP	2
?	1277 460 H91	TUBE, RIGHT ROD END	1
?	25 553 R1	WASHER, FLAT - 3/8	2
?	25 522 R1	NUT, HEX - 3/8NC	1
?	1277 461 H91	TUBE, LEFT ROD END	1
?	25 553 R1	WASHER, FLAT - 3/8	2
?	25 522 R1	NUT, HEX - 3/8NC	1
?	9410 204	CONNECTOR	4
?	364 885 R1	RING, SEAL	4
