| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1308 099 H91 | VALVE ASSY, BRAKE | 1 | ||||
| ? | 1277 191 H1 | • WIPER, INPUT SPOOL | 1 | ||||
| ? | (NSS) | • HOUSING, VALVE | 1 | ||||
| ? | (NSS) | • SPOOL, INPUT | 1 | ||||
| ? | (NSS) | • SPOOL, METERING | 1 | ||||
| ? | 1280 454 H1 | • STOP, SPOOL | 1 | ||||
| ? | 1280 455 H1 | • WASHER | 1 | ||||
| ? | 1308 143 H1 | • SPRING, OUTER METERING | 1 | ||||
| ? | 1306 895 H1 | • COVER, END | 1 | ||||
| ? | 1280 458 H1 | • SPRING, SPOOL RETURN | 1 | ||||
| ? | 1306 892 H1 | • RETAINER, SEAL | 1 | ||||
| ? | 25 493 R1 | • BOLT, HEX - 5/16NCx1 | 4 | ||||
| ? | 25 543 R1 | • WASHER, FLAT - 5/16 | 4 | ||||
| ? | 364 839 R1 | • RING, SEAL | 1 | ||||
| ? | 610 261 C1 | • PLUG, PORT | 1 | ||||
| ? | 1306 381 H1 | • SPRING, INNER METERING | 1 | ||||
| ? | 1308 328 H1 | • GUIDE, SPRING | 1 | ||||
| ? | 309 041 R1 | • RING, SEAL | 1 |
