Номер на схеме	Каталожный номер	Название	Количество
?		SHOE, APPLY (SEE PG 04-016)	-29	04AVTD9H.002
?	621 025 C1	SHAFT, ECCENTRIC	4
?	621 026 C1	WASHER, THRUST	8
?	621 027 C1	ARM, LEFT STEERING	1
?	621 028 C1	ARM, RIGHT STEERING	1
?	621 032 C1	ARM, LEFT BRAKE	1
?	621 033 C1	ARM, RIGHT BRAKE	1
?	621 036 C1	RING, RETAINING	4
?		SHOE, BACK UP (SEE PG 04-016)	-29	04AVTD9H.002
?	360 677 R1	SPRING, ARM RETURN	2
?	621 039 C1	SCREW, STEERING SHOE ADJUSTMENT	2
?	621 822 C1	PLATE, SCREW LOCK	2
?	24 839 R1	BOLT, HEX - 3/8NCx3/4	2
?	120 930	WASHER, LOCK - 3/8	2
?	621 040 C1	SCREW, BRAKE SHOE ADJUSTMENT	2
?	219 760	NUT, JAM - 1NF	2
?	733 233 C92	PLATE ASSY, LEFT MOUNTING	1
?	(733 225 C92)	• PLATE ASSY, LEFT	-54	F1
?	(NSS)	• • PLATE, LEFT	1
?	621 087 C1	• • PIN, DOWEL	2
?	621 090 C91	• BEARING, NEEDLE	2
?	24 864 R1	BOLT, HEX - 1/2NCx2	3
?	25 546 R1	WASHER, FLAT - 1/2	3
?	733 234 C92	PLATE ASSY, RIGHT MOUNTING	1
?	(733 226 C92)	• PLATE ASSY, RIGHT	-54	F1
?	(NSS)	• • PLATE, RIGHT	1
?	621 087 C1	• • PIN, DOWEL	2
?	621 090 C91	• BEARING, NEEDLE	2
?	24 864 R1	BOLT, HEX - 1/2NCx2	3
?	25 546 R1	WASHER, FLAT - 1/2	3
?	733 227 C1	SPACER, PLATE MOUNTING	4
?
?		F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.
?
