Номер на схеме	Каталожный номер	Название	Количество
?	(1269 045 H91)	CONTROL ASSY, THROTTLE	-54	F1
?	740 465 C91	• BEARING, SEALED - OPTIONAL	2
?	740 766 C91	• BEARING, SEALED - OPTIONAL	2
?	747 101 C1	• BEARING, SEALED - OPTIONAL	2
?	1258 293 H91	• CONTROL, THROTTLE	1
?	109 454	• FITTING, LUBE	1
?	(1281 123 H91)	BELLCRANK, THROTTLE CONTROL	-54	F1
?	740 465 C91	• BEARING, SEALED - OPTIONAL	2
?	740 766 C91	• BEARING, SEALED - OPTIONAL	2
?	747 101 C1	• BEARING, SEALED - OPTIONAL	2
?	1281 124 H91	• BELLCRANK, THROTTLE	1
?	109 454	• FITTING, LUBE	1
?	1269 907 H1	• SEAL, OIL	2
?
?		F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.
?
