| Наименование | Страница | Код страницы |
|---|---|---|
| FIG. H0210-01A0 MAIN PUMP - FRONT CASE ASSEMBLY | H-046 | H0210-01A0 |
| FIG. H0210-01A0 MAIN PUMP - FRONT CASE ASSEMBLY | H-046 | H0210-01A0 |
| FIG. H0210-01A0 MAIN PUMP - FRONT CASE ASSEMBLY | H-046 | H0210-01A0 |
| FIG. H0210-02A0 MAIN PUMP - END CAP ASSEMBLY | H-048 | H0210-02A0 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 708-2L-32110 | SHAFT, FRONT | 1 | SN: A85001-- |
|||
| ? | 708-2L-22150 | BEARING | 1 | SN: A85001-- |
|||
| ? | 708-2E-05040 | WASHER KIT | 1 | SN: A85001-- |
|||
| ? | 708-2E-12160 | • WASHER, 3.1 MM | 1 | SN: A85001-- |
|||
| ? | 708-2E-12170 | • WASHER, 3.0 MM | 1 | SN: A85001-- |
|||
| ? | 708-2E-12180 | • WASHER, 2.9 MM | 1 | SN: A85001-- |
|||
| ? | 708-2E-12190 | • WASHER, 2.8 MM | 1 | SN: A85001-- |
|||
| ? | 708-25-12790 | RING, SNAP | 1 | SN: A85001-- |
|||
| ? | 708-25-52860 | SEAL, OIL | 1 | SN: A85001-- |
|||
| ? | 708-2L-22160 | SPACER | 1 | SN: A85001-- |
|||
| ? | 04065-06825 | RING, SNAP | 1 | SN: A85001-- |
|||
| ? | 708-2L-04141 | BLOCK ASSEMBLY, FRONT | 1 | SN: A85001-- |
|||
| ? | (NSS) | • BLOCK, CYLINDER | 1 | SN: A85001-- |
|||
| ? | (NSS) | • PLATE, VALVE | 1 | SN: A85001-- |
|||
| ? | 720-68-19610 | PIN | 1 | SN: A85001-- |
|||
| ? | 04065-04818 | RING, SNAP | 1 | SN: A85001-- |
|||
| ? | 708-2L-23131 | SEAT | 1 | SN: A85001-- |
|||
| ? | 708-2L-33160 | SPRING | 1 | SN: A85001-- |
|||
| ? | 708-7L-13140 | SEAT | 1 | SN: A85001-- |
|||
| ? | 708-2L-23351 | GUIDE, RETAINER | 1 | SN: A85001-- |
|||
| ? | 708-2L-23360 | PIN | 3 | SN: A85001-- |
|||
| ? | 708-2L-33340 | RETAINER, SHOE | 1 | SN: A85001-- |
|||
| ? | 708-2L-33310 | PISTON SUB ASSEMBLY | 9 | SN: A85001-- |
|||
| ? | 708-2L-04361 | CRADLE ASSEMBLY, FRONT | 1 | SN: A85001-- |
|||
| ? | (NSS) | • CRADLE | 1 | SN: A85001-- |
|||
| ? | (NSS) | • CAM, ROCKER | 1 | SN: A85001-- |
