| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1296 096 H91 | CAMSHAFT ASSY | 1 | ||||
| ? | 1238 817 H2 | • CAMSHAFT | 1 | ||||
| ? | 1239 150 H1 | • BEARING, CAMSHAFT THRUST | 1 | ||||
| ? | 1239 172 H1 | • GEAR, CAMSHAFT | 1 | ||||
| ? | 1238 584 H1 | • KEY, PLAIN WOODRUFF | 1 | ||||
| ? | 1240 025 H1 | • LOCKPLATE | 2 | ||||
| ? | 1238 008 H1 | • BOLT, MOUNTING - 3/8NCx1 | 2 | ||||
| ? | 1241 370 H1 | SHAFT, IDLER | 2 | ||||
| ? | 1239 089 H91 | GEAR, BUSHING CAM IDLER | 1 | ||||
| ? | (NSS) | • GEAR, IDLER | 1 | ||||
| ? | 1239 091 H1 | • BUSHING | 1 | ||||
| ? | 1239 090 H91 | GEAR, BUSHING WATER PUMP IDLER | 1 | ||||
| ? | (NSS) | • GEAR, IDLER | 1 | ||||
| ? | 1239 091 H1 | • BUSHING | 1 | ||||
| ? | 1238 259 H1 | BEARING, THRUST | 4 | ||||
| ? | 1238 813 H1 | BOLT, TWELVE POINT - 5/8NFx3 | 2 | ||||
| ? | 1239 884 H1 | WASHER, PLAIN | 2 |
