| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (747 204 C91) | CRANKCASE GUARD | -54 | F1 | |||
| ? | (1259 469 H91) | CRANKCASE GUARD | -54 | F1 | |||
| ? | 1207 701 H92 | • GUARD, CRANKCASE | 1 | ||||
| ? | 27 968 R1 | • BOLT, MOUNTING - 1NCx2-1/4 | 10 | ||||
| ? | 67 574 DC | • COVER ASSY, DRAIN HOLE | 2 | ||||
| ? | 650 374 C1 | • • BAR, ACCESS COVER | 1 | ||||
| ? | (NSS) | • • COVER, ACCESS | 1 | ||||
| ? | 24 862 R1 | • • BOLT, MOUNTING - 1/2NCx1-1/2 | 1 | ||||
| ? | 25 536 R1 | • • WASHER, FLAT - 1/2 | 1 | ||||
| ? | 617 931 C2 | • SPACER | 10 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? |
