| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (737 222 C91) | BACK UP ALARM - FACTORY | -54 | F1 | |||
| ? | (1218 964 H91) | BACK UP ALARM - FIELD | -54 | F1 | |||
| ? | 740 986 C2 | • SWITCH, ALARM - IN PILOT VALVE MANIFOLD | 1 | ||||
| ? | 737 188 C1 | • ALARM, BACK UP | 1 | a | |||
| ? | 736 131 C2 | • ALARM, BACK UP | 1 | b | |||
| ? | 189 295 | • BOLT, MOUNTING - 3/8NCx4-1/2 | 2 | ||||
| ? | 390 305 C1 | • WASHER, FLAT - 3/8 | 2 | ||||
| ? | 21 622 R1 | • NUT, HEX - 3/8NC | 2 | ||||
| ? | 306 132 C2 | • STRAP, TIE | 1 | ||||
| ? | 266 770 R91 | • CABLE, GROUND | 1 | ||||
| ? | 740 365 C1 | • CABLE, POWER | 1 | ||||
| ? | 338 064 R1 | • GROMMET, CABLE | 1 | ||||
| ? | HARNESS, MAIN (SEE PG 08-002) | -29 | 08-002 | ||||
| ? | HARNESS, SWITCH (SEE PG 08-002) | -29 | 08-002 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? |
