| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (737 218 C91) | OPEN ROPS LIGHTING - FACTORY | -54 | F1 | |||
| ? | (1218 975 H91) | OPEN ROPS LIGHTING - FIELD | -54 | F1 | |||
| ? | 703 416 C1 | • GUARD, FRONT LIGHT | 2 | ||||
| ? | 208 490 R1 | • BOLT, MOUNTING - 7/16NCx1 | 12 | ||||
| ? | 25 645 R1 | • WASHER, FLAT - 1/2 | 12 | ||||
| ? | 120 384 | • WASHER, LOCK - 1/2 | 12 | ||||
| ? | 303 706 R1 | • SWIVEL, LIGHT | 3 | ||||
| ? | 168 392 R1 | • BOLT, MOUNTING - 1/2NCx2-1/2 | 3 | ||||
| ? | 120 384 | • WASHER, LOCK - 1/2 | 3 | ||||
| ? | 21 330 R1 | • NUT, HEX - 1/2NC | 3 | ||||
| ? | • LIGHT, WORK (SEE PG 08-044) | -29 | 08-044 | ||||
| ? | 120 384 | • WASHER, LOCK - 1/2 | 3 | ||||
| ? | 225 857 | • NUT, HEX - 1/2NF | 3 | ||||
| ? | 740 351 C1 | • CABLE, HARNESS TO LIGHT | 2 | ||||
| ? | 138 530 | • WASHER, LOCK - No.8 | 2 | ||||
| ? | 703 060 C1 | • CABLE, LIGHT TO LIGHT | 1 | ||||
| ? | 138 530 | • WASHER, LOCK - No.8 | 1 | ||||
| ? | 34 048 H | • GROMMET, RUBBER | 2 | ||||
| ? | 651 628 C1 | • GUARD, REAR LIGHT | 1 | ||||
| ? | 454 998 | • BOLT, MOUNTING - 1/2NCx1 | 4 | ||||
| ? | 25 645 R1 | • WASHER, FLAT - 1/2 | 4 | ||||
| ? | 120 384 | • WASHER, LOCK - 1/2 | 4 | ||||
| ? | 21 330 R1 | • NUT, HEX - 1/2NC | 4 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? |
