| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (1200 283 H91) | COLD START BATTERIES | -54 | F1 | |||
| ? | 1269 028 H1 | • BATTERY, WET CHARGED - HW-3107002 | 6 | a | |||
| ? | 1200 274 H1 | • BATTERY, DRY CHARGED - HD-3107002 | 6 | b | |||
| ? | 476 074 C1 | • NUT, TERMINAL | 16 | ||||
| ? | 1200 254 H1 | • CHANNEL, MOUNTING | 2 | ||||
| ? | 27 433 R1 | • BOLT, MOUNTING - 1/2NCx2 | 4 | ||||
| ? | 25 536 R1 | • WASHER, FLAT - 1/2 | 4 | ||||
| ? | 1200 278 H2 | • CABLE, BATTERY TO BATTERY | 4 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? |
