| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 737 164 C91 | LIGHT ASSY, WORK - HOBBS | 2 | ||||
| ? | 28 169 R1 | • BEAM, SEALED - TRADE #4813 | 1 | ||||
| ? | 313 957 R1 | • RETAINER, BEAM | 1 | ||||
| ? | (NSS) | • HOUSING, LIGHT | 1 | ||||
| ? | (NSS) | • SCREW, TERMINAL - #8x3/8 | 1 | ||||
| ? | 138 530 | • WASHER, LOCK - #8 | 1 | ||||
| ? | (NSS) | • INSULATOR | 1 | a | |||
| ? | 737 165 C91 | LIGHT ASSY, WORK - GUIDE LAMP | 2 | b | |||
| ? | 28 169 R1 | • BEAM, SEALED - TRADE #4813 | 1 | ||||
| ? | 338 896 R1 | • RETAINER, BEAM | 1 | ||||
| ? | (NSS) | • HOUSING, LIGHT | 1 | ||||
| ? | 111 302 | • SCREW, TERMINAL - #8 | 1 | ||||
| ? | 120 622 | • NUT, LOCK - #8 | 1 | ||||
| ? | 138 530 | • WASHER, LOCK - #8 | 1 | ||||
| ? | (NSS) | • PLATE, TERMINAL | 1 |
