Номер на схеме	Каталожный номер	Название	Количество
?	662 285 C95	VALVE ASSY, PRESSURE REGULATOR	1
?	(NSS)	• HOUSING, VALVE	1
?	(662 287 C92)	• SPOOL ASSY, MAIN	-54	F1
?	(NSS)	• • SPOOL, MAIN	1
?	17 010 R1	• • BALL, CHECK	1
?	662 291 C3	• • SPRING, CHECK BALL	1
?	17 067 R1	• • PIN, SPRING	1
?	662 290 C1	• PIN, SPRING GUIDE	1
?	666 019 C2	• SPRING, MAIN SPOOL OUTER	1
?	666 018 C2	• SPRING, MAIN SPOOL INNER	1
?	662 294 C1	• SHIM, MAIN SPOOL - UP TO MAX OF 3	A/R	F2
?	662 294 C1	• SHIM, CONVERTER SPOOL - UP TO MAX OF 5	A/R	F2
?	662 294 C1	• SHIM, LUBE SPOOL - UP TO MAX OF 3	A/R	F2
?	382 137 R1	• O-RING	6	F2
?	666 128 C2	• SPRING, CONVERTER SPOOL	1
?	666 020 C2	• SPRING, LUBE SPOOL	1
?	(NSS)	• SPOOL, LUBE	1
?	(NSS)	• SPOOL, CONVERTER	1
?	662 296 C1	• COVER, END	1
?	25 955 R1	• BOLT, MOUNTING - 5/16NCx5/8	8
?	116 120	• WASHER, LOCK - 5/16	8
?	444 692	• PLUG, PORT	1
?	104 938	• PLUG, CORK	1
?
?		F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.
?
?
?		F2 - PART OF TRANSMISSION SERVICE KIT 741 459 C94 LISTED ON PG 07-036.
?
