| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (635 591 C91) | TRACK CHAIN | -54 | F1 | |||
| ? | 617 089 C94 | • CHAIN ASSY, TRACK | 2 | ||||
| ? | 740 536 C1 | • • SPLIT LINK, RIGHT - BUSHING END | 1 | ||||
| ? | 740 535 C1 | • • SPLIT LINK, LEFT - BUSHING END | 1 | ||||
| ? | 314 840 R1 | • • BUSHING, TRACK LINK | 38 | ||||
| ? | 314 842 R1 | • • PIN, TRACK, LINK | 38 | ||||
| ? | 616 212 C1 | • • WASHER, BELLEVILLE | 152 | ||||
| ? | 616 211 C3 | • • LINK, RIGHT, TRACK | 37 | ||||
| ? | 616 210 C3 | • • LINK, LEFT, TRACK | 37 | ||||
| ? | 740 533 C1 | • • SPLIT LINK, LEFT - PIN END | 1 | ||||
| ? | 740 534 C1 | • • SPLIT LINK, RIGHT - PIN END | 1 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? |
