| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 728 151 C94 | UNIT ASSY, ROOF | 1 | ||||
| ? | 739 626 C1 | • HOSE, LIQUID | 1 | ||||
| ? | 383 024 R1 | • O-RING | 1 | ||||
| ? | 27 475 R1 | • O-RING | 2 | ||||
| ? | 739 605 C1 | • TUBE, WATER | 2 | ||||
| ? | 739 604 C1 | • TUBE, SUCTION | 1 | ||||
| ? | • UNIT, CONDENSER (SEE PG 13-112) | -29 | 13-112 | ||||
| ? | (NSS) | • BOLT, MOUNTING - 3/8NCx3/4 | 7 | ||||
| ? | (NSS) | • WASHER, LOCK - 3/8 | 7 | ||||
| ? | 1211 509 H91 | • HOUSING ASSY, LEFT FILTER | 1 | ||||
| ? | (NSS) | • • HOUSING, FILTER | 1 | ||||
| ? | 739 559 C1 | • • GASKET, HOUSING | 1 | ||||
| ? | 739 627 C91 | • • FILTER ASSY, FRESH AIR | 1 | ||||
| ? | (NSS) | • • • FILTER, AIR | 1 | ||||
| ? | (NSS) | • • • SEAL, FILTER | 1 | ||||
| ? | (NSS) | • SCREW, MOUNTING - 1/4NCx1 | 3 | ||||
| ? | (NSS) | • BOLT, MOUNTING - 1/4NCx1-1/2 | 4 | ||||
| ? | (NSS) | • WASHER, LOCK - 1/4 | 7 | ||||
| ? | 1211 508 H91 | • HOUSING ASSY, RIGHT FILTER | 1 | ||||
| ? | (NSS) | • • HOUSING, FILTER | 1 | ||||
| ? | 739 559 C1 | • • GASKET, HOUSING | 1 | ||||
| ? | 739 627 C91 | • • FILTER ASSY, FRESH AIR | 1 | ||||
| ? | (NSS) | • • • FILTER, AIR | 1 | ||||
| ? | (NSS) | • • • SEAL, FILTER | 1 | ||||
| ? | (NSS) | • SCREW, MOUNTING - 1/4NCx1 | 3 | ||||
| ? | (NSS) | • BOLT, MOUNTING - 1/4NCx1-1/2 | 4 | ||||
| ? | (NSS) | • WASHER, LOCK - 1/4 | 7 | ||||
| ? | • UNIT, BLOWER AND COIL (SEE PG 13-116) | -29 | 13-116 | ||||
| ? | (NSS) | • SEAL, BETWEEN HOUSING | 1 | ||||
| ? | (NSS) | • BUSHING, STRESS RELIEF | 1 |
