| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 886 255 C1 | KIT, MOUNTING | 2 | ||||
| ? | 728 411 C1 | • PLATE ASSEMBLY, PIVOT MOUNTING | 2 | ||||
| ? | (NSS) | • • PLATE, MOUNTING | 1 | ||||
| ? | (NSS) | • • NUT, WIPER ARM | 1 | ||||
| ? | 728 412 C1 | • GASKET, MOUNTING PLATE | 1 | ||||
| ? | 181 568 | BOLT, MOUNTING - 1/4NFx1 | 4 | ||||
| ? | 9413 965 | NUT, LOCK - 1/4NF | 4 | ||||
| ? | MOTOR, LEFT WIPER (SEE PG 13-084) | -29 | 13-084 | ||||
| ? | 729 329 C1 | BAR, WIPER SPACER | A/R | ||||
| ? | 24 839 R1 | BOLT, MOUNTING - 3/8NCx3/4 | 1 | ||||
| ? | 25 534 R1 | WASHER, FLAT - 3/8 | 1 | ||||
| ? | 9413 979 | NUT, LOCK - 3/8NC | 1 | ||||
| ? | MOTOR, RIGHT WIPER (SEE PG 13-082) | -29 | 13-082 | ||||
| ? | 729 329 C1 | BAR, WIPER SPACER | A/R | ||||
| ? | 24 839 R1 | BOLT, MOUNTING - 3/8NCx3/4 | 1 | ||||
| ? | 25 534 R1 | WASHER, FLAT - 3/8 | 1 | ||||
| ? | 9413 979 | NUT, LOCK - 3/8NC | 1 | ||||
| ? | 644 283 C91 | ARM, WIPER | 2 | ||||
| ? | 163 195 R91 | BLADE, WIPER | 2 | a | |||
| ? | 346 909 C1 | BLADE, WIPER | 2 | b | |||
| ? | 739 344 C1 | GUARD, WIPER MOTOR | 2 | ||||
| ? | 25 222 R1 | BOLT, MOUNTING - 1/4NCx3/4 | 4 | ||||
| ? | 25 532 R1 | WASHER, FLAT - 1/4 | 4 |
