| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 743 555 C91 | FRAME ASSY, SEAT | 1 | ||||
| ? | 637 444 C91 | • ROD ASSY | 1 | ||||
| ? | (NSS) | • • ROD | 1 | ||||
| ? | 603 909 C1 | • • SPRING, TORSION | 1 | ||||
| ? | 160 541 | • SCREW, MOUNTING - 1/4NCx3/4 | 2 | ||||
| ? | 103 319 | • WASHER, LOCK - 1/4 | 2 | ||||
| ? | 383 296 R1 | • SPRING, LINKAGE | 2 | ||||
| ? | 603 912 C1 | • EXTENSION, LEFT SPRING | 1 | ||||
| ? | 603 913 C1 | • SPRING, LINKAGE ARM | 1 | ||||
| ? | 193 653 R1 | • BEARING, PIVOT | 8 | ||||
| ? | 378 480 R1 | • PIN, HEADED | 2 | ||||
| ? | 18 518 R1 | • PIN, SPRING | 2 | ||||
| ? | 21 931 R1 | • PIN, ROD END | 4 | ||||
| ? | 17 175 R1 | • PIN, SPRING | 4 | ||||
| ? | 25 637 R1 | • WASHER, FLAT - 1/2 | 2 | ||||
| ? | 681 973 C1 | • SPACER, FRAME | 2 | ||||
| ? | (NSS) | • FRAME, UPPER | 1 | ||||
| ? | (NSS) | • FRAME, LOWER LEFT | 1 | ||||
| ? | (NSS) | • FRAME, LOWER RIGHT | 1 | ||||
| ? | (NSS) | • LINK, FRONT | 1 | ||||
| ? | (NSS) | • LINK AND HANDLE, CENTER | 1 | ||||
| ? | (NSS) | • LINK, REAR | 1 |
