| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1238 113 H1 | WASHER, PLAIN | 8 | ||||
| ? | 1238 701 H1 | O-RING | 1 | ||||
| ? | 1238 722 H1 | BOLT, MOUNTING | 8 | ||||
| ? | 1239 110 H1 | SEAL, OIL | 1 | ||||
| ? | 1239 160 H1 | PLUG, PIPE | 1 | ||||
| ? | 1239 554 H1 | HOUSING, FLYWHEEL | 1 | ||||
| ? | 1237 988 H1 | BOLT, MOUNTING | 12 | ||||
| ? | 1238 100 H1 | WASHER, LOCK | 12 | ||||
| ? | 1240 090 H1 | DOWEL | 14 | ||||
| ? | 1238 427 H1 | SEAL, RECTANGULAR RING | 12 | ||||
| ? | 1238 699 H1 | SEAL, RECTANGULAR RING | 1 | ||||
| ? | 1239 929 H1 | PLUG, MAGNETIC | 1 | ||||
| ? | 1239 973 H1 | GASKET, PLUG | 1 |
