| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1239 665 H92 | GEAR ASSY, FUEL PUMP | 1 | ||||
| ? | (NSS) | • HOUSING, FUEL PUMP GEAR | 1 | ||||
| ? | (NSS) | • COVER, FUEL PUMP GEAR | 1 | ||||
| ? | 1240 073 H1 | • BOLT, SOCKET HEAD | 2 | ||||
| ? | 1240 059 H1 | • WASHER, PLAIN | 2 | ||||
| ? | 1238 480 H1 | • WASHER, LOCK | 2 | ||||
| ? | 1239 657 H1 | • DOWEL, RING | 1 | ||||
| ? | 1238 185 H1 | • GASKET, FUEL PUMP | 1 | ||||
| ? | 1239 352 H91 | • GEAR AND SHAFT | 1 | ||||
| ? | 1238 216 H1 | • • GEAR, FUEL PUMPING | 1 | ||||
| ? | 1238 138 H1 | • • SHAFT, FUEL PUMP DRIVE | 1 | ||||
| ? | 1239 432 H91 | • GEAR AND SHAFT | 1 | ||||
| ? | 1238 216 H1 | • • GEAR, FUEL PUMPING | 1 | ||||
| ? | 1238 438 H1 | • • SHAFT, FUEL PUMP | 1 | ||||
| ? | 1239 985 H1 | • DOWEL, PIN | 2 | ||||
| ? | 1239 660 H91 | • VALVE ASSY, CHECK | 1 | ||||
| ? | 1239 669 H1 | • • O-RING | 1 | ||||
| ? | 1239 669 H1 | • • O-RING | 1 | ||||
| ? | 1250 120 H1 | • VALVE, PRESSURE REGULATOR | 1 | ||||
| ? | 1239 661 H91 | • PLUG, THREADED | 1 | ||||
| ? | 1239 529 H1 | GASKET, FUEL PUMP | 1 |
