| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1250 684 H91 | PUMP ASSY, LUBRICATING OIL | 1 | ||||
| ? | 1238 025 H1 | • BOLT, MOUNTING - 3/8NCx2-1/2 | 2 | ||||
| ? | 1238 035 H1 | • BOLT, MOUNTING - 3/8NCx2-3/4 | 1 | ||||
| ? | 186 285 | • BOLT, MOUNTING - 3/8NCx4 | 1 | ||||
| ? | 1240 067 H1 | • DOWEL, PIN | 1 | ||||
| ? | 1238 166 H1 | • DOWEL, DIAMOND | 1 | ||||
| ? | 1238 657 H1 | • GASKET, LUBE OIL PUMP | 1 | ||||
| ? | 1238 796 H1 | • GEAR, LUBRICATING OIL PUMP | 1 | ||||
| ? | 1238 342 H1 | • GEAR, LUBRICATING OIL PUMP | 2 | ||||
| ? | 120 382 | • WASHER, LOCK | 4 | ||||
| ? | 1238 662 H1 | • PLUNGER, PRESSURE REGULATOR | 1 | ||||
| ? | 1238 654 H1 | • SHAFT, IDLER | 1 | ||||
| ? | 1267 116 H1 | • SPRING, COMPRESSION | 1 | ||||
| ? | 1239 889 H1 | • PLUG, RETAINER | 1 | ||||
| ? | 1238 655 H91 | • BODY ASSY, LUBRICATING OIL PUMP | 1 | ||||
| ? | (NSS) | • • BODY, LUBRICATING OIL PUMP | 1 | ||||
| ? | 1240 036 H1 | • • BUSHING | 4 | ||||
| ? | 1238 658 H1 | • SHAFT, LUBE OIL PUMP | 1 | ||||
| ? | 1241 346 H91 | • COVER, LUBE OIL PUMP | 1 | ||||
| ? | 1295 951 H1 | **COVER, LUBE OIL PUMP | 1 | ||||
| ? | 140 483 H | BOLT W/WASHER - 3/8NCx1-1/4 | 3 | ||||
| ? | 1238 745 H1 | O-RING | 2 | ||||
| ? | 1238 785 H1 | O-RING | 1 |
