| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1238 363 H1 | BOLT, MOUNTING - 5/8NCx2-1/4 | 6 | ||||
| ? | 1238 236 H1 | WASHER, PLAIN | 6 | ||||
| ? | 1238 806 H1 | SUPPORT, FRONT ENGINE | 1 | ||||
| ? | 1237 992 H1 | ELBOW, MALE ADAPTER | 1 | ||||
| ? | 1239 515 H1 | PLUG, PIPE | 6 | ||||
| ? | 1239 184 H1 | SPRING, ENGINE BARRING | 1 | ||||
| ? | 118 406 | BUSHING | 2 | ||||
| ? | 1238 671 H1 | BUSHING | 1 | ||||
| ? | 1239 361 H1 | SEAL, OIL | 1 | ||||
| ? | 1239 360 H1 | SEAL, OIL | 1 | ||||
| ? | 1239 362 H1 | SEAL, OIL | 1 | ||||
| ? | 1241 331 H91 | COVER, GEAR | 1 | ||||
| ? | 1239 336 H1 | RING, RETAINING | 1 | ||||
| ? | 1239 413 H91 | GUIDE ASSY, BARRING SHAFT | 1 | ||||
| ? | 1239 410 H1 | • BUSHING | 1 | ||||
| ? | 1239 411 H1 | • BEARING, THRUST | 1 | ||||
| ? | 1239 412 H1 | • PIN, ROLL | 1 | ||||
| ? | (NSS) | • GUIDE, BARRING SHAFT | 1 | ||||
| ? | 1239 415 H1 | GEAR, ENGINE BARRING | 1 | ||||
| ? | 1239 416 H1 | SHAFT, BARRING | 1 | ||||
| ? | 1246 131 H91 | PLUG, THREADED | 2 | ||||
| ? | 1241 358 H1 | PLUG, DRIVE | 1 | ||||
| ? | 1239 901 H1 | O-RING | 1 | ||||
| ? | 1239 882 H1 | PLATE, CLAMPING | 1 | ||||
| ? | 1240 053 H1 | DOWEL, PIN | 1 | ||||
| ? | 1238 152 H1 | DOWEL, DIAMOND | 1 | ||||
| ? | 1239 321 H1 | BOLT W/WASHER - 3/8NCx1 | 12 | ||||
| ? | 1239 722 H1 | GASKET, COVER PLATE | 1 | ||||
| ? | 1238 132 H1 | PLUG, PIPE | 1 | ||||
| ? | 1238 753 H1 | STUD | 1 | ||||
| ? | 1238 754 H1 | STUD | 1 | ||||
| ? | 1239 440 H1 | NUT, PLUG - 3/8NC | 2 | ||||
| ? | (NSS) | PLATE, GEAR COVER | 1 |
