| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1241 565 H91 | KIT, TURBO | 1 | ||||
| ? | 1238 594 H1 | • GASKET, CONNECTION | 1 | ||||
| ? | 1252 716 H1 | • GASKET, CONNECTION | 1 | ||||
| ? | 1238 764 H1 | • GASKET, TURBOCHARGER | 1 | ||||
| ? | 1252 177 H1 | • O-RING | 2 | ||||
| ? | 1239 056 H1 | • SEAL, DUST | 1 | ||||
| ? | 1241 648 H91 | • TURBOCHARGER ASSY | 1 | ||||
| ? | (NSS) | • • HOUSING, COMPRESSOR | 1 | ||||
| ? | 1241 398 H1 | • • CLAMP, V-BAND | 1 | ||||
| ? | 1241 387 H1 | • • NUT, LOCK | 1 | ||||
| ? | (NSS) | • • IMPELLER, TURBO COMPRESSOR | 1 | ||||
| ? | 1241 409 H1 | • • BOLT, MOUNTING | 4 | ||||
| ? | 1241 385 H1 | • • WASHER, PLAIN | 4 | ||||
| ? | 1241 408 H1 | • • DIFFUSER, TURBOCHARGER | 1 | ||||
| ? | 1240 489 H1 | • • O-RING | 1 | ||||
| ? | 1241 401 H1 | • • SEAL, SPLIT RING | 1 | ||||
| ? | 1241 404 H1 | • • SLINGER, OIL | 1 | ||||
| ? | 1241 406 H1 | • • BAFFLE, OIL | 1 | ||||
| ? | 1241 405 H1 | • • SHIM | 1 | ||||
| ? | 1242 024 H1 | • • BEARING, TURBO THRUST | 1 | ||||
| ? | 1241 388 H1 | • • COLLAR, THRUST | 1 | ||||
| ? | 1241 390 H1 | • • RING, RETAINING | 4 | ||||
| ? | 1241 389 H1 | • • BEARING, TURBOCHARGER | 2 | ||||
| ? | 1241 402 H1 | • • HOUSING, TURBO BEARING | 1 | ||||
| ? | 1241 391 H1 | • • SHIELD, TURBOCHARGER HEAT | 1 | ||||
| ? | 1241 393 H1 | • • BOLT, MOUNTING | 8 | ||||
| ? | 1241 395 H1 | • • SEAL, SPLIT RING | 1 | ||||
| ? | 1241 392 H1 | • • SHAFT AND WHEEL | 1 | ||||
| ? | 1241 552 H2 | • • HOUSING, TURBINE | 1 | ||||
| ? | 1240 491 H1 | • • NUT, HEX | 1 | ||||
| ? | 1241 399 H1 | • • LOCK PLATE | 4 | ||||
| ? | (NSS) | • • DATA PLATE | 1 | ||||
| ? | 1246 471 H1 | • • SCREW, DRIVE | 1 | ||||
| ? | 1242 019 H91 | KIT, TURBO BEARING, SEAL | 1 |
