| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1239 466 H93 | HEAD ASSY, CYLINDER | 6 | R1 | |||
| ? | (NSS) | • HEAD, CYLINDER | 1 | ||||
| ? | 1238 663 H1 | • COLLET, VALVE | 8 | ||||
| ? | 1239 016 H1 | • GUIDE, VALVE SPRING | 4 | ||||
| ? | 1238 665 H1 | • RETAINER, VALVE SPRING | 4 | ||||
| ? | 1238 695 H1 | • SPRING, VALVE | 4 | ||||
| ? | 1239 681 H92 | • VALVE, EXHAUST | 2 | ||||
| ? | 1238 792 H2 | • VALVE, INTAKE | 2 | ||||
| ? | 1238 687 H1 | • GUIDE, CROSSHEAD VALVE | 2 | ||||
| ? | 1241 642 H1 | • GUIDE, VALVE STEM | 4 | ||||
| ? | 1238 664 H1 | • INSERT, VALVE | 2 | ||||
| ? | 1240 019 H1 | • PIN, GROOVE | 2 | ||||
| ? | 1239 530 H1 | • INSERT, VALVE | 2 | ||||
| ? | 1238 721 H1 | • PLUG, EXPANSION | 8 | ||||
| ? | 1238 755 H1 | • PLUG, EXPANSION | 2 | ||||
| ? | 1240 004 H1 | • PLUG, PIPE | 1 | ||||
| ? | 1238 125 H1 | • PLUG, PIPE | 1 | ||||
| ? | 1238 634 H1 | • PLUG, EXPANSION | 1 | ||||
| ? | 1239 635 H1 | BOLT, TWELVE POINT | 36 | ||||
| ? | 1238 656 H1 | WASHER, PLAIN | 36 | ||||
| ? | 1241 635 H91 | GASKET ASSY, CYLINDER HEAD | 1 | ||||
| ? | 1238 741 H1 | • SEAL, GROMMET | 6 | ||||
| ? | 1238 812 H1 | • SEAL, GROMMET | 24 | ||||
| ? | 1238 742 H1 | • SEAL, GROMMET | 18 | ||||
| ? | 1238 743 H1 | • SEAL, GROMMET | 6 | ||||
| ? | 1238 627 H1 | NUT, HEX | 12 | ||||
| ? | 1250 683 H91 | CROSSHEAD, VALVE | 12 | ||||
| ? | 1239 637 H1 | SCREW, CROSSHEAD VALVE ADJUSTING | 12 | ||||
| ? | 1241 598 H2 | GASKET, CYLINDER HEAD - 0.020 IN OVER | A/R | ||||
| ? | |||||||
| ? | R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED | ||||||
| ? | ASSEMBLIES CATALOG. |
