| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (1303 885 H91) | AIR CLEANER AND CONNECTIONS | -54 | F1 | |||
| ? | • BRACKET, FRONT MOUNTING (SEE PG 12-146) | -29 | 12-146 | ||||
| ? | 26 310 R1 | • BOLT, MOUNTING - 3/8NCx1 | 5 | ||||
| ? | 25 544 R1 | • WASHER, FLAT - 3/8 | 5 | ||||
| ? | • BRACKET, REAR MOUNTING (SEE PG 12-146) | -29 | 12-146 | ||||
| ? | 26 310 R1 | • BOLT, MOUNTING - 3/8NCx1 | 5 | ||||
| ? | 25 544 R1 | • WASHER, FLAT - 3/8 | 5 | ||||
| ? | • AIR CLEANER (SEE PG 12-010) | -29 | 12-010 | ||||
| ? | 1200 350 H1 | • HOSE, AIR CLEANER OUTLET | 1 | ||||
| ? | 1234 166 H1 | • CLAMP, HOSE | 1 | ||||
| ? | 437 923 R91 | • CLAMP, HOSE | 1 | ||||
| ? | 1200 360 H1 | • CLAMP, AIR CLEANER MOUNTING | 2 | ||||
| ? | 24 861 R1 | • BOLT, MOUNTING - 1/2NCx1-1/4 | 2 | ||||
| ? | 24 865 R1 | • BOLT, MOUNTING - 1/2NCx2-1/4 | 1 | ||||
| ? | 25 555 R1 | • WASHER, FLAT - 1/2 HDN | 4 | ||||
| ? | 25 526 R1 | • NUT, HEX - 1/2NC | 2 | ||||
| ? | (NSS) | • BODY, PRE-CLEANER | 1 | ||||
| ? | 1303 886 H1 | • PRE-CLEANER ASSY | 1 | ||||
| ? | (NSS) | • • PRE-CLEANER | 1 | ||||
| ? | 1303 887 H1 | • • BEARING | 1 | ||||
| ? | (NSS) | • CLAMP | 2 | ||||
| ? | 25 654 R1 | • BOLT, MOUNTING - 5/16NCx1-1/2 | 2 | ||||
| ? | 25 520 R1 | • NUT, HEX - 5/15NC | 2 | ||||
| ? | SWITCH, VACUUM (SEE PG 08-014) | -29 | 08-014 | ||||
| ? | 138 805 | SCREW, SET - 1/2NCx2-3/4 | 1 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? |
