| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1277 904 H92 | CLUSTER ASSY, GAUGE | 1 | ||||
| ? | 1277 905 C2 | • LENS, WARNING | 1 | ||||
| ? | 739 719 C2 | • LENS, WARNING | 1 | ||||
| ? | 1216 148 H2 | • GAUGE, TRANSMISSION TEMPERATURE | 1 | ||||
| ? | 1216 147 H1 | • GAUGE, COOLANT TEMPERATURE | 1 | ||||
| ? | 1104 081 C1 | • VOLTMETER | 1 | ||||
| ? | 739 878 C1 | • GAUGE, ENGINE OIL PRESSURE | 1 | ||||
| ? | 27 727 R1 | • BULB, LIGHT - #464 | 8 | ||||
| ? | 121 608 C1 | • BEZEL, CLUSTER | 1 | ||||
| ? | 121 611 C2 | • SOCKET, BULB | 8 | ||||
| ? | (NSS) | • HOUSING, CLUSTER | 1 |
