| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 733 844 C92 | CYLINDER ASSY, BLADE TILT | 1 | ||||
| ? | 733 877 C91 | • HOUSING ASSY, CYLINDER | 1 | ||||
| ? | (NSS) | • • HOUSING | 1 | ||||
| ? | 319 286 R1 | • • BUSHING | 1 | ||||
| ? | 20 532 R1 | • NUT, LOCK - 2NF | 1 | ||||
| ? | 27 262 R1 | • WASHER, FLAT - 2 | 1 | ||||
| ? | 1233 274 H1 | • PISTON | 1 | ||||
| ? | 636 234 C92 | • PACKAGE, SEAL RING SERVICE | 1 | ||||
| ? | (NSS) | • • O-RING | 2 | ||||
| ? | (NSS) | • • RING, WEAR | 2 | ||||
| ? | (NSS) | • • RING, PISTON | 1 | ||||
| ? | (NSS) | • • O-RING, CAP SEALING | 1 | ||||
| ? | (NSS) | • • O-RING | 1 | ||||
| ? | 658 673 C1 | • • RING, BACK-UP | 1 | ||||
| ? | (NSS) | • • O-RING | 1 | ||||
| ? | (NSS) | • • RING, BUFFER | 1 | ||||
| ? | (NSS) | • • RING, WEAR | 1 | ||||
| ? | (NSS) | • • SEAL, ROD | 1 | ||||
| ? | (NSS) | • • SEAL, WIPER | 1 | ||||
| ? | 1233 397 H1 | • GLAND | 1 | ||||
| ? | 191 304 H2 | • SEGMENTS, LOCK RING | 3 | ||||
| ? | 933 270 C1 | • COVER, CYLINDER | 1 | ||||
| ? | 27 406 R1 | • BOLT, MOUNTING - 1/2NCx1-3/4 | 6 | ||||
| ? | 25 536 R1 | • WASHER, FLAT - 1/2 | 6 | ||||
| ? | 658 666 C91 | • ROD ASSY, CYLINDER | 1 | ||||
| ? | (NSS) | • • ROD | 1 | ||||
| ? | 319 286 R1 | • • BUSHING | 1 |
