| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1297 411 H91 | VALVE ASSY, QUICK DROP | 1 | ||||
| ? | (NSS) | • HOUSING, VALVE | 1 | ||||
| ? | (NSS) | • SPOOL, VALVE | 1 | ||||
| ? | 1297 415 H1 | • SPRING, INNER | 1 | ||||
| ? | 1297 416 H1 | • SPRING, OUTER | 1 | ||||
| ? | 1297 417 H1 | • RETAINER, SPRING | 1 | ||||
| ? | 1297 418 H1 | • PLATE, COVER | 1 | ||||
| ? | 30 022 R1 | • BOLT, MOUNTING - M10x35 | 4 | ||||
| ? | 30 184 R1 | • WASHER, FLAT - M10 | 4 | ||||
| ? | 307 915 R1 | • O-RING | 1 | ||||
| ? | 343 921 R1 | • O-RING | 1 | ||||
| ? | 610 262 C1 | • PLUG, O-RING | 1 |
