| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 705 075 C1 | SHAFT, IDLER | 1 | ||||
| ? | 707 253 R1 | RING, SEAL | 1 | F1 | |||
| ? | 627 094 C91 | BEARING ASSY, DOUBLE TAPERED ROLLER | 1 | ||||
| ? | (NSS) | • BEARING, TAPERED ROLLER | 2 | ||||
| ? | 619 386 R91 | • • CONE, BEARING | 1 | ||||
| ? | 619 387 R1 | • • CUP, BEARING | 1 | ||||
| ? | (NSS) | • SPACER, BEARING CONE | 1 | ||||
| ? | 627 095 C1 | SPACER, BEARING CUP | 1 | ||||
| ? | 705 033 C1 | GEAR, REVERSE IDLER | 1 | ||||
| ? | 659 919 C1 | RETAINER, SHAFT | 1 | ||||
| ? | 27 432 R1 | BOLT, HEX - 3/4NCx1-3/4 PATCH | 1 | ||||
| ? | |||||||
| ? | F1 - PART OF TRANSMISSION SERVICE KIT 741 453 C93. | ||||||
| ? |
