| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 666 151 C95 | VALVE ASSY, PILOT CONTROL | 1 | ||||
| ? | (NSS) | • HOUSING, VALVE | 1 | ||||
| ? | (NSS) | • SPOOL, VALVE | 1 | ||||
| ? | 1270 948 H1 | • CAM, DETENT | 1 | ||||
| ? | 369 751 R1 | • RING, SEAL | 1 | ||||
| ? | 1270 945 H1 | • RETAINER, BALL | 1 | ||||
| ? | 17 013 R1 | • BALL, DETENT | 4 | ||||
| ? | 1270 946 H1 | • SLEEVE, DETENT | 1 | ||||
| ? | 659 017 C1 | • SPRING, DETENT | 1 | ||||
| ? | 307 915 R1 | • RING, SEAL | 1 | ||||
| ? | 622 332 C3 | • HOUSING, DETENT | 1 | ||||
| ? | 1269 756 H1 | • SEAL, SPOOL WIPER | 1 |
