| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1260 469 H91 | HOUSING ASSY, REAR | 1 | F1 | |||
| ? | 619 956 C1 | • GASKET, HUB | 1 | F2 | |||
| ? | 619 964 C1 | • HUB, GROUND SLEEVE | 1 | ||||
| ? | ST 205 A | • BEARING, BALL | 4 | ||||
| ? | 619 955 C1 | • GEAR, SPUR | 2 | ||||
| ? | 625 062 C1 | • RING, SEAL | 1 | F2 | |||
| ? | 625 916 C1 | • RING, RETAINING | 2 | ||||
| ? | 659 380 R1 | • RING, RETAINING | 2 | ||||
| ? | 619 967 C1 | • HOUSING, REAR | 1 | ||||
| ? | 619 958 C1 | • HUB, RETAINER | 1 | ||||
| ? | 619 957 C1 | • GASKET, HUB | 1 | F2 | |||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - PART OF TORQUE CONVERTER SEAL KIT 625 879 C93. | ||||||
| ? |
