| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 706 980 C91 | PUMP ASSY, CHARGE AND SCAVENGE | 1 | ||||
| ? | 27 712 R1 | • BOLT, HEX - 3/8NCx6-3/4 | 4 | ||||
| ? | 27 713 R1 | • BOLT, HEX - 3/8NCx7 | 4 | ||||
| ? | (NSS) | • PLATE, FRONT | 1 | ||||
| ? | 637 937 C91 | • KIT, REPAIR | 1 | ||||
| ? | (NSS) | • • RING, RETAINING | 1 | ||||
| ? | (NSS) | • • SEAL, OIL | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 4 | ||||
| ? | (NSS) | • • BALL, CHECK | 2 | ||||
| ? | (NSS) | • • SPRING, BALL CHECK | 2 | ||||
| ? | (NSS) | • • SEAL, DIAPHRAGM | 2 | ||||
| ? | (NSS) | • • GASKET, PROTECTOR | 2 | ||||
| ? | (NSS) | • • GASKET, BACK UP | 2 | ||||
| ? | (NSS) | • • DIAPHRAGM, FRONT | 1 | ||||
| ? | (NSS) | • • PLATE, THRUST | 2 | ||||
| ? | (NSS) | • • DIAPHRAGM, REAR | 1 | ||||
| ? | (NSS) | • PIN, DOWEL | 2 | ||||
| ? | (NSS) | • KEY, GEAR | 1 | ||||
| ? | (NSS) | • HOUSING, FRONT | 1 | ||||
| ? | (NSS) | • GEAR AND SHAFT, DRIVE | 1 | ||||
| ? | (NSS) | • GEAR AND SHAFT, IDLER | 1 | ||||
| ? | (NSS) | • HOUSING, CENTER | 1 | ||||
| ? | (NSS) | • PIN, DOWEL | 2 | ||||
| ? | (NSS) | • GEAR, REAR | 2 | ||||
| ? | (NSS) | • HOUSING, REAR | 1 | ||||
| ? | (NSS) | • PLATE, BACK | 1 | ||||
| ? | 1210 683 H1 | • WASHER, SEAL RETAINER | 1 |
