| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1269 788 H91 | FAN SHROUDS AND GUARDS | 1 | F1 | |||
| ? | 1278 564 H1 | • SHROUD, UPPER FAN | 1 | ||||
| ? | 26 309 R1 | • BOLT, HEX - 3/8NCx3/4 | 4 | ||||
| ? | 25 544 R1 | • WASHER, FLAT - 3/8 | 4 | ||||
| ? | 1278 565 H1 | • SHROUD, LOWER FAN | 1 | ||||
| ? | 26 309 R1 | • BOLT, HEX - 3/8NCx3/4 | 4 | ||||
| ? | 25 544 R1 | • WASHER, FLAT - 3/8 | 4 | ||||
| ? | 1269 740 H91 | • GUARD, RIGHT FAN | 1 | ||||
| ? | 25 493 R1 | • BOLT, HEX - 5/16NCx1 | 4 | ||||
| ? | 1311 024 H1 | • WASHER, SPECIAL | 4 | ||||
| ? | 1269 739 H91 | • GUARD, LEFT FAN | 1 | ||||
| ? | 25 493 R1 | • BOLT, HEX - 5/16NCx1 | 5 | ||||
| ? | 1311 024 H1 | • WASHER, SPECIAL | 5 | ||||
| ? | 25 520 R1 | • NUT, HEX - 5/16NC | 1 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? |
