| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 540 976 R93 | SHANK ASSY, RIPPER | 3 | ||||
| ? | 547 315 R1 | • POINT, TOOTH | 1 | ||||
| ? | 492 406 R1 | • PIN, FLEX | 1 | ||||
| ? | (NSS) | • SHANK, RIPPER | 1 | ||||
| ? | 701 494 C91 | ADDITIONAL RIPPER TOOTH | 1 | F1 | |||
| ? | 540 976 R93 | • SHANK ASSY, RIPPER | 1 | ||||
| ? | 547 315 R1 | • • POINT, TOOTH | 1 | ||||
| ? | 492 406 R1 | • • PIN, FLEX | 1 | ||||
| ? | (NSS) | • • SHANK, RIPPER | 1 | ||||
| ? | 492 472 R2 | • PIN, MOUNTING - HEADED TYPE | 1 | F2 | |||
| ? | 180 044 | • BOLT, HEX - 1/4NCx2 | 1 | ||||
| ? | 23 911 R1 | • NUT, LOCK - 1/4NC | 1 | ||||
| ? | 1303 822 H1 | • PIN, MOUNTING | 1 | ||||
| ? | 180 044 | • BOLT, HEX - 1/4NCx2 | 1 | ||||
| ? | 23 911 R1 | • NUT, LOCK - 1/4NC | 1 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - USED WITH EARLY STYLE TOOLBARS ONLY. | ||||||
| ? |
