| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1280 192 H91 | HAND STEERING | 1 | F1 | |||
| ? | 1280 700 H1 | • CONSOLE, LEFT | 1 | ||||
| ? | 25 222 R1 | • BOLT, HEX - 1/4NCx3/4 | 4 | ||||
| ? | 25 542 R1 | • WASHER, FLAT - 1/4 | 4 | ||||
| ? | 1280 629 H91 | • LEVER ASSY, LEFT STEERING | 1 | ||||
| ? | 1280 628 H1 | • • LEVER, LEFT STEERING | 1 | ||||
| ? | 740 465 C91 | • • BEARING, SEALED | 2 | ||||
| ? | 126 152 | • • FITTING, LUBE | 1 | ||||
| ? | • LINK, DOUBLE ADJUSTABLE (SEE PG 05-004) | -29 | F2;05ADTD9H.003 | ||||
| ? | 1280 632 H91 | • LEVER ASSY, RIGHT STEERING | 1 | ||||
| ? | 1280 631 H1 | • • LEVER, RIGHT STEERING | 1 | ||||
| ? | 740 465 C91 | • • BEARING, SEALED | 2 | ||||
| ? | 126 152 | • • FITTING, LUBE | 1 | ||||
| ? | • LINK, DOUBLE ADJUSTABLE (SEE PG 05-004) | -29 | F2;05ADTD9H.003 | ||||
| ? | 1223 254 H1 | • SHAFT, LEVER | 1 | ||||
| ? | 19 975 R1 | • PIN, ROLL | 1 | ||||
| ? | 1278 137 H91 | • LINK ASSY, SINGLE ADJUSTABLE | 2 | F3 | |||
| ? | 1278 075 H91 | • • LINK, VALVE | 1 | ||||
| ? | 144 254 | • • CLEVIS, ROD END | 1 | ||||
| ? | 25 934 R1 | • • NUT, JAM - 3/8NF | 1 | ||||
| ? | 16 617 R1 | • PIN, CLEVIS - 3/8x1-1/16 | 2 | ||||
| ? | 103 374 | • PIN, COTTER - 3/32x1 | 2 | ||||
| ? | 432 759 | • PIN, CLEVIS - 1/4x49/64 | 2 | ||||
| ? | 103 361 | • PIN, COTTER - 1/16x1/2 | 2 | ||||
| ? | • PRODUCT GRAPHIC, STEERING (SEE PG 02-002) | -29 | 02ADTD8H.001 | ||||
| ? | VALVE AND HOSES, STEERING (SEE PG 07-018) | -29 | 07BHTD9H.004 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - 35640 AND UP. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F3 - 35639 AND DOWN. | ||||||
| ? |
