| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1269 466 H91 | PUMP ASSY, EQUIPMENT | 1 | ||||
| ? | 1299 969 H1 | • KIT, SEAL | 1 | ||||
| ? | (NSS) | • • SPRING, BALL | 2 | ||||
| ? | (NSS) | • • BALL, CHECK | 2 | ||||
| ? | (NSS) | • • RING, SEAL | 2 | ||||
| ? | (NSS) | • • GASKET, BACK UP | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • • SEAL, DIAPHRAGM | 1 | ||||
| ? | (NSS) | • • GASKET, PROTECTOR | 1 | ||||
| ? | (NSS) | • • DIAPHRAGM | 1 | ||||
| ? | (NSS) | • • PLATE, THRUST | 1 | ||||
| ? | 202 207 H1 | • BOLT, HEX - 3/8NCx3-1/4 | 4 | ||||
| ? | 25 635 R1 | • BOLT, HEX - 3/8NCx3-1/2 | 4 | ||||
| ? | (NSS) | • FRONT PLATE | 1 | ||||
| ? | (NSS) | • GEAR, DRIVE | 1 | ||||
| ? | (NSS) | • GEAR, DRIVEN | 1 | ||||
| ? | (NSS) | • PIN, DOWEL | 2 | ||||
| ? | (NSS) | • BODY, PUMP | 1 | ||||
| ? | (NSS) | • REAR PLATE | 1 |
