| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1300 751 H91 | RESERVOIR ASSY, EQUIPMENT | 1 | ||||
| ? | 1300 710 H91 | • WELDMENT, RESERVOIR | 1 | ||||
| ? | 1300 743 H91 | • COVER, VALVE ACCESS | 1 | ||||
| ? | 24 839 R1 | • BOLT, HEX - 3/8NCx3/4 | 4 | ||||
| ? | 25 534 R1 | • WASHER, FLAT - 3/8 | 4 | ||||
| ? | • DOOR, RESERVOIR (SEE PG 10-034) | -29 | 10BV789H.002 | ||||
| ? | 24 838 R1 | • BOLT, HEX - 3/8NCx1/2 | 3 | ||||
| ? | 390 305 C1 | • WASHER, FLAT - 3/8 | 3 | ||||
| ? | 1300 708 H91 | • STRIKER, DOOR | 1 | ||||
| ? | 390 305 C1 | • WASHER, FLAT - 3/8 | 2 | ||||
| ? | 25 523 R1 | • NUT, HEX - 3/8NF | 2 | ||||
| ? | 1299 593 H91 | • HANDLE, GRAB | 1 | ||||
| ? | 24 839 R1 | • BOLT, HEX - 3/8NCx3/4 | 4 | ||||
| ? | 25 534 R1 | • WASHER, FLAT - 3/8 | 4 | ||||
| ? | 1303 290 H2 | • HANDLE, FEATHERING | 1 | ||||
| ? | 24 859 R1 | • BOLT, HEX - 1/2NCx3/4 | 2 | ||||
| ? | 120 384 | • WASHER, LOCK - 1/2 | 2 | ||||
| ? | 1308 809 H1 | • LINK, DOOR STAY | 1 | ||||
| ? | 20 791 R1 | • PIN, CLEVIS - 1/4x7/8 | 1 | ||||
| ? | 22 256 R1 | • WASHER, FLAT - 9/32 | 1 | ||||
| ? | 103 361 | • PIN, COTTER - 1/16x1/2 | 1 | ||||
| ? | 1302 398 H1 | • SPRING, KEEPER | 1 | ||||
| ? | 23 840 R1 | • PIN, CLEVIS - 5/16x1-3/16 | 1 | ||||
| ? | 120 393 | • WASHER, FLAT - 5/16 | 1 | ||||
| ? | 119 117 | • PIN, COTTER - 3/32x1/2 | 1 | ||||
| ? | 294 118 R2 | • PLUG, FILL | 1 | ||||
| ? | 253 172 R1 | • RING, SEAL | 1 | ||||
| ? | 9410 360 | • PLUG, DRAIN | 1 | ||||
| ? | 368 269 R1 | • RING, SEAL | 1 | ||||
| ? | 1214 473 H91 | • VALVE ASSY, VACUUM PRESSURE RELIEF | 1 | ||||
| ? | 927 994 C1 | • • FILTER | 1 | ||||
| ? | 883 170 C91 | • • KIT, VALVE REPAIR | 1 | ||||
| ? | 296 247 R1 | • RING, SEAL | 1 | ||||
| ? | 933 022 C1 | • GAUGE, SIGHT | 1 | ||||
| ? | 364 145 R1 | • RING, SEAL | 1 | ||||
| ? | 1269 422 H1 | • STRAINER, SUCTION | 1 | ||||
| ? | 307 916 R1 | • RING, SEAL | 1 | ||||
| ? | • FILTER, EQUIPMENT (SEE PG 10-036) | -29 | 10BVTD9H.002 | ||||
| ? | 24 839 R1 | • BOLT, HEX - 3/8NCx3/4 | 2 | ||||
| ? | 25 553 R1 | • WASHER, FLAT - 3/8 | 2 | ||||
| ? | 1269 409 H1 | • ADAPTER, FILTER | 1 | ||||
| ? | 296 247 R1 | • RING, SEAL | 1 | ||||
| ? | 9410 981 | • ELBOW, 90° | 1 | ||||
| ? | 296 247 R1 | • RING, SEAL | 1 | ||||
| ? | 1306 539 H1 | • SEAL, DOOR | 2 | ||||
| ? | 157 313 | • ADHESIVE CONTACT - 1QT | 1 | ||||
| ? | 1308 472 H1 | • PLATE, COVER | 1 | ||||
| ? | 145 384 | • SCREW, #7 DRIVE | 4 | ||||
| ? | 1266 312 H1 | SHIM, MOUNTING | A/R | ||||
| ? | 1300 746 H91 | COVER, RESERVOIR | 1 | ||||
| ? | 24 839 R1 | BOLT, HEX - 3/8NCx3/4 | 5 | ||||
| ? | 25 534 R1 | WASHER, FLAT - 3/8 | 5 |
