| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1278 546 H91 | RESERVOIR AND FILTER | 1 | ||||
| ? | 1279 475 H91 | • RESERVOIR | 1 | ||||
| ? | 1269 408 H1 | • PLATE, SIDE COVER | 1 | ||||
| ? | 24 839 R1 | • BOLT, HEX - 3/8NCx3/4 | 4 | ||||
| ? | 25 534 R1 | • WASHER, FLAT - 3/8 | 4 | ||||
| ? | 294 118 R2 | • PLUG, FILL | 1 | ||||
| ? | 253 172 R1 | • RING, SEAL | 1 | ||||
| ? | 9410 361 | • PLUG, DRAIN | 1 | ||||
| ? | 368 269 R1 | • RING, SEAL | 1 | ||||
| ? | 1214 473 H91 | • VALVE ASSY, VACUUM PRESSURE RELIEF | 1 | ||||
| ? | 927 994 C1 | • • FILTER | 1 | ||||
| ? | 883 170 C91 | • • KIT, VALVE REPAIR | 1 | ||||
| ? | 296 247 R1 | • RING, SEAL | 1 | ||||
| ? | 933 022 C1 | • GAUGE, SIGHT | 1 | ||||
| ? | 364 145 R1 | • RING, SEAL | 1 | ||||
| ? | 1269 422 H1 | • STRAINER, SUCTION | 1 | ||||
| ? | 307 916 R1 | • RING, SEAL | 1 | ||||
| ? | • FILTER, EQUIPMENT (SEE PG 10-036) | -29 | 10BVTD9H.002 | ||||
| ? | 24 839 R1 | • BOLT, HEX - 3/8NCx3/4 | 2 | ||||
| ? | 25 553 R1 | • WASHER, FLAT - 3/8 | 2 | ||||
| ? | 1269 409 H1 | • ADAPTER, FILTER | 1 | ||||
| ? | 296 247 R1 | • RING, SEAL | 1 | ||||
| ? | 9410 981 | • ELBOW, 90° | 1 | ||||
| ? | 296 247 R1 | • RING, SEAL | 1 | ||||
| ? | 1266 312 H1 | SHIM, MOUNTING | A/R |
