| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1299 237 H91 | VALVE ASSY, ANTI CAVITATION | 1 | ||||
| ? | 1299 236 H1 | • KIT, SEAL | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • • RING, BACK UP | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • • RING, BACK UP | 2 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • BODY, CHECK BALL | 1 | ||||
| ? | 666 719 R1 | • POPPET, CHECK | 1 | ||||
| ? | 1435 685 H1 | • SPRING, POPPET | 1 | ||||
| ? | 1435 688 H1 | • BALL, CHECK | 1 | ||||
| ? | 1435 690 H1 | • RETAINER, CHECK BALL | 1 |
