| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1299 223 H91 | SECTION ASSY, BLADE LIFT | 1 | ||||
| ? | • POSITIONER, DETENT (SEE PG 10-062) | -29 | 10BHTD9H.002 | ||||
| ? | • VALVE, LOAD CHECK (SEE PG 10-066) | -29 | 10BHTD9H.006 | ||||
| ? | • VALVE, ANTI-CAVITATION (SEE PG 10-068) | -29 | 10BHTD9H.007 | ||||
| ? | (1299 238 H91) | • SEAL ASSY, SPOOL | -54 | F1 | |||
| ? | 1299 239 H1 | • • KIT, SPOOL SEAL | 1 | ||||
| ? | (NSS) | • • • WASHER, BACK UP | 1 | ||||
| ? | (NSS) | • • • RING, SEAL | 1 | ||||
| ? | 850 880 C1 | • • RETAINER | 1 | ||||
| ? | 1299 240 H1 | • KIT, SEAL PLATE | 1 | ||||
| ? | (NSS) | • • PLATE, SEAL | 1 | F2 | |||
| ? | (NSS) | • • BOLT, HEX - 1/4NCx1/2 | 2 | ||||
| ? | (NSS) | • SPOOL, SECTION | 1 | ||||
| ? | (NSS) | • HOUSING, SECTION | 1 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - FOR SHIPPING PURPOSES ONLY. USE FOR SERVICING SECTION. | ||||||
| ? |
