| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1299 230 H91 | VALVE ASSY, SYSTEM RELIEF | 1 | ||||
| ? | (NSS) | • SCREEN, FILTER | 1 | ||||
| ? | (NSS) | • RING, RETAINING | 1 | ||||
| ? | (NSS) | • POPPET, MAIN RELIEF | 1 | ||||
| ? | (NSS) | • BODY, VALVE | 1 | ||||
| ? | (NSS) | • CAP, END | 1 | ||||
| ? | (NSS) | • NUT, JAM | 1 | ||||
| ? | (NSS) | • SCREW, ADJUSTING | 1 | ||||
| ? | (NSS) | • POPPET, PILOT | 1 | ||||
| ? | 1299 231 H1 | • KIT, SEAL | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • • RING, BACK-UP | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • • RING, BACK-UP | 1 | ||||
| ? | (NSS) | • • RING, BACK-UP | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • • RING, SEAL | 1 | ||||
| ? | (NSS) | • SPRING, MAIN RELIEF POPPET | 1 | ||||
| ? | (NSS) | • SPRING, PILOT POPPET | 1 | ||||
| ? | (NSS) | • WASHER, FLAT - 3/8 | 1 |
